GsProtector

Installation Extract the zip archiv and place the files in your root mohaa folder (where the mohaa executable is) and restart your game server. (Important: Please change the passwords in the GsProtector.ini file: rconpw and loginpw to strong passwords.) You should then when you start your server see a GsProtector_logfile.txt generated in your server folder. You can also test with a rcon gpstatus if all is setup properly. Deinstallation Remove (all) the files from your root mohaa folder and restart your game server. Anti Flooding / Anti Lag and Auto ban Flooders Banning Firewall bans GsProtector offers the ability to issue IP bans directly in the windows firewall. To make use of this option the gameserver has to be started with sufficient rights, usually as administrator, and the settings have to be set accordingly which are: pathToNetsh: the path to netsh.exe, usually "c:\Windows\System32\netsh.exe" appPort: the listening port of your gameserver e.g. 12203. This is used as identifier in the firewall, aswell as blocking the IP only for this specific port (this applys to winserver 2008/win7 only, on win2003/win2000/xp all ports will be banned for that IP) FirewallBans: set here whether to allow firewall bans or not Please note: If firewall bans aren't allowed and Banning is set to 2 no bans will be issued Caution on win2003/2000/xp server, if u test-ban yourself make sure you can access the firewall somehow.

The Config Files GsProtector is controlled via 2 config files: GsProtector.ini and GsProtector_Host.ini The GsProtector_Host.ini has settings for the Gameserver Hoster: [common] FirewallBans=0 OperatingSystem=0 GameType=0 pathToNetsh="c:\Windows\System32\netsh.exe" appPort="12203" FirewallBans: wheter to allow (1) or disallow (0) bans in the firewall of the windows server. OperatingSystem: 0= WinServer2008/ Win7/Vista, 1= WinServer 2000/2003/XP GameType: The type of the Gameserver, e.g. 0=Mohaa, 1= Spearhead/Breakthrough pathToNetsh: The full path to the netsh.exe command line tool (required for firewall control) appPort: The listening Port of the gameserver. Also used as identifier for bans in the firewall The GsProtector.ini has these settings: [common] Banning=1 AntiFlood=1 AutoBanFloods=1 MaxQueriesPerSec=50 MaxRconPerSec=10 MaxConnectPerSec=10 PrintInfo=1 AutoUnBan=3 AutoUnBanHours=24 WlQueries=0 WlRcon=0 WlJoin=0 ImmuneList=1 Logging=1 FloodValueMs=50 FloodPacketsThreshold=5 FloodPacketsIP=10 performChallenge=0 rconpw="thepw" loginpw="thepw" Banning: 0=off, 1= internal bans only, 2 = firewall bans only, 3 = internal and firewall bans Shielding and Login This is a mode meant mainly for war servers. Players register with the server by doing a login. War admin handles out the gploginpw to the players, they do a "rcon <gploginpw> login" in their ingame console or via a rcon tool. Now the war admin sets the Shield to 1 and the server is in shield-mode which means only those players previously logged in can join or play, getstatus queries to the server are limited and also only those player registered can issue rcon commmands. It is like a passworded server with the addition that it also cares about query and rcon requests. Whitelists and Immunelists GsProtector offers Whitelist for Join/Connected Players, Rcon and Queries and an Immunelist to immunisize IP's. Immunelist: No checks will be done for network packets that come from IP that have been immunisized Rcon command to add IP to the Immunelist: ImmuneAdd <IP> Rcon command to remove IP from the Immunelist: ImmuneRem <IP> Whitelist: IP's on a Whitelist are exclusively allowed for the server if the specific whitelist is turned on. Rcon command to add IP to a Whitelist: WlAdd <WlType> <IP> wlType: [0,1,2] (0=queries, 1=rcon, 2= join) Rcon command to remove IP from a Whitelist: WlAdd <WlType> <IP> wlType: [0,1,2] (0=queries, 1=rcon, 2= join) You need to specify to which Whitelist you want to add the IP with the WlType. Example: As Admin of your server you want to be the only one allowed to issue rcon commands in the server, then you add your IP to the Rcon Whitelist: rcon WlAdd 1 192.168.0.255 Where 1 specifies the type of the Whitelist = here Rcon and 192.168.0.255 is your actual IP. Now you turn on the Whitelist for Rcon with: rcon WlRcon 1 Alternatively you can also do a login with the server (as described in Topic Shielding) which adds your IP automatically to all Whitelists and turn on the Whitelist for Rcon only. Remote Crash Fixes The GsProtector protects versus different remote crash attacs. However it does not fix any vulnerabilities that are related to the gameserver engine itself like mohbuf fill attac. Log files These logfiles will be created: GsProtector_logfile.txt Contains info about the status of GsProtector If Logging is set to 1 then Rcon, Player Connects will be written to log files. If PrintInfo is set 1 information about the packets that have been sent to the gameserver in a timeinterval like how many queries, how many banned packets will be written to the log file. =======Sun Apr 01 17:23:40 2012 Config settings loaded, GS Protector working. =======Sun Apr 01 17:23:40 2012 Gameserver Protector Current Config Settings: OperatingSystem= 0 appPort= 12203 loginpw= test Banning= 1 AntiFlood= 1 AntiLag= 1 MaxQueriesPerSec= 50 MaxRconPerSec= 10 MaxConnectPerSec= 10 PrintInfo= 1 AutoUnBan= 3 AutoUnBanHours= 24 WlQueries= 0 WlRcon= 0 WlJoin= 0 ImmuneList= 1 Logging= 1 FloodPacketsMs= 50 FloodPacketsThreshold= 5 FloodPacketsIP= 10 performChallenge= 0 Shield= 0 =======Sun Apr 01 17:25:42 2012 Received Packets Info. Timespan: 60001 ms Packets: 16 Queries: 16 Banned Packets: 0 Connect Packets: 0 Rcon Packets: 0 GsProtector_PlayerConnectDetails.txt Details of the player connecting to the gameserver will be written into this file. GsProtector_log_attacking_IPs.txt If an attac is detected the IP of the attacker is written to this file. Rcon Commands These are Rcon Commands you can use: Banning [0,1,2,3] (0=off, 1=internal bans, 2=firewall bans, 3= internal + firewall bans) AntiFlood [0,1] AutoBanFloods [0,1] MaxQueriesPerSec [10-9999] MaxRconPerSec [10-9999] MaxConnectPerSec [10-9999] PrintInfo [0,1] AutoUnBan [0,1] AutoUnBanHours [1-9999] WlQueries [0,1] WlRcon [0,1] WlJoin [0,1] ImmuneList [0,1] Logging [0,1] FloodValueMs [20-750] FloodPacketsThreshold [3-50] FloodPacketsIP [3-50] performChallenge [0,1] loginpw <String> GpReset GpStatus GpBanIP <IP> GpUnbanIP <IP> WlAdd <WlType> <IP> wlType: [0,1,2] (0=queries, 1=rcon, 2= join) WlRem <WlType> <IP> wlType: [0,1,2] (0=queries, 1=rcon, 2= join) ImmuneAdd <IP> ImmuneRem <IP> In brackets the possible values. Flood Testing modder has provided a page where you can test if your game server is vulnerable to floods (rconpassword required): http://x-null.net/getstatus/getstatus.php For the testing, enable logging of your game server so that it prints query requests to the logfile, start then with the testing, if you find all of the 100 queries in your logfile your server is vulnerable to flooding attacs.

Credits: modder, members of TMT (www.modtheater.com), AAAA (www.mohaaaa.co.uk), Armageddon (www.crazygamersclan.com) Mad Max (www.cipclan.com), xnull (www.x-null.net)
